Description
- This CSD86360Q5D specialized power IC from Texas Instruments is ideal for odd components with unusual power needs. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This USB PWM controller has a maximum operating temperature of 125 °C.
CSD86360Q5D Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | LSON-CLIP-8 |
| Number of Positions | 8 Position |
| Drain to Source Resistance (on) (Rds) | 3.7 Ω |
| Polarity | Dual N-Channel |
| Power Dissipation | 13 W |
| Threshold Voltage | 1 V |
| Drain to Source Voltage (Vds) | 25 V |
| Input Power (Max) | 13 W |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 13000 mW |
| Supply Voltage (Max) | 22 V |
| Show | |
| Size-Length | 6 mm |
| Size-Width | 5 mm |
| Size-Height | 1.5 mm |
| Operating Temperature | -55℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance Edition | 2015/06/15 |
| ECCN Code | EAR99 |
