DAC0832LCN - TI
Manufacturer:
TI
ManyChip's Part#:
MC23254929
Category:
Digital to Analog, DAC IC
Package:
DIP-20
Datasheet:
Datasheet 3D Model
Description:
TEXAS INSTRUMENTS DAC0832LCN Digital to Analogue Converter, 8Bit, Parallel, 4.75V to 15.75V, DIP, 20Pins
Stock Locations:
Availability:
625 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 3.18

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The DAC0832LCN is a 8-bit microprocessor compatible, double-buffered Digital-to-analogue Converter. A deposited silicon-chromium R-2R resistor ladder network divides the reference current and provides the circuit with excellent temperature tracking characteristics (0.05% of Full Scale Range maximum linearity error over-temperature). The circuit uses CMOS current switches and control logic to achieve low power consumption and low output leakage current errors. Special circuitry provides TTL logic input voltage level compatibility. Double buffering allows these DACs to output a voltage corresponding to one digital word while holding the next digital word. This permits the simultaneous updating of any number of DACs.
Double-buffered, single-buffered or flow-through digital data inputs
Direct interface to all popular microprocessors
Linearity specified with zero and full scale adjust only-not best straight line fit
Can be used in the voltage switching mode
Operates "STAND ALONE" (without µP) if desired
This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.

Show

DAC0832LCN Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	20 Pin
Case/Package	DIP-20
Number of Outputs	1 Output
Supply Current	1.20 mA
Number of Channels	1 Channel
Number of Positions	20 Position
Number of Bits	8 Bit
Power Dissipation	0.5 W
Sample Rate	1.00 mHz
Power Consumption	20 mW
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	500 mW
Supply Voltage	4.75V ~ 15.75V
	Show
Size-Height	3.3 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
