DAC08AQ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC737108
Category:
Digital to Analog, DAC IC
Package:
CDIP-16
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES DAC08AQ Digital to Analog Converter, 8Bit, Parallel, ± 4.5V to ± 18V, DIP, 16Pins
Stock Locations:
Availability:
325 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 31.18

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

GENERAL DESCRIPTION
The DAC08 series of 8-bit monolithic digital-to-analog convert ers provide very high speed performance coupled with low cost and outstanding applications flexibility.
FEATURES
Fast settling output current: 85 ns
Full-scale current prematched to ±1 LSB
Direct interface to TTL, CMOS, ECL, HTL, PMOS
Nonlinearity to 0.1% maximum over temperature range
High output impedance and compliance: −10 V to +18 V
Complementary current outputs
Wide range multiplying capability: 1 MHz bandwidth
Low FS current drift: ±10 ppm/°C
Wide power supply range: ±4.5 V to ±18 V
Low power consumption: 33 mW @ ±5 V
Low cost

Show

DAC08AQ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	CDIP-16
Number of Outputs	1 Output
Number of Channels	1 Channel
Number of Bits	8 Bit
Power Dissipation	0.174 W
Sample Rate	11.8 Msps
Resolution (Bits)	8.0 Bit
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	174 mW
Number of DACs	1 DAC
	Show
Size-Height	3.56 mm
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	3A001.a.2.c
