- DAC8412FPCZ - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC814771
-
Category:Digital to Analog, DAC IC
-
Package:PLCC-28
-
Datasheet:Datasheet 3D Model
-
Description:ANALOG DEVICES DAC8412FPCZ Digital to Analog Converter, 12Bit, 167KSPS, Parallel, ± 4.75V to ± 5.25V, ± 14.25V to ± 15.75V
-
Stock Locations:
-
Availability:267 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 8.55
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The DAC8412FPCZ is a quad 12-bit voltage output Digital-to-analog Converter (DAC) with read-back capability. Output voltage swing is set by the two reference inputs VREFH and VREFL. By setting the VREFL input to 0V and VREFH to a positive voltage, the DAC provides unipolar positive output range. A similar configuration with VREFH at 0V and VREFL at a negative voltage provides unipolar negative output range. Bipolar outputs are configured by connecting both VREFH and VREFL to non-zero voltages. This method of setting output voltage range has advantages over other bipolar offsetting methods because it is not dependent on internal and external resistors with different temperature coefficients. Digital controls allow the user to load or read back data from any DAC, load any DAC and transfer data to DAC at one time. An active low RESET load of DAC output registers to midscale for the DAC8412.
- Built using a complementary BiCMOS process
- True voltage output
- Double-buffered inputs
- Reset to centre scale
- Fast bus access time
DAC8412FPCZ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 28 Pin |
| Case/Package | PLCC-28 |
| Supply Voltage (DC) | 15.0V (max) |
| Number of Outputs | 4 Output |
| Supply Current | 8.5 mA |
| Number of Channels | 4 Channel |
| Number of Positions | 28 Position |
| Number of Bits | 12 Bit |
| Power Dissipation | 0.33 W |
| Sample Rate | 167 ksps |
| Resolution (Bits) | 12.0 Bit |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 330 mW |
| Number of DACs | 4 DAC |
| Supply Voltage (Max) | 15 V |
| Supply Voltage (Min) | 5 V |
| Show | |
| Size-Length | 11.58 mm |
| Size-Width | 11.58 mm |
| Size-Height | 3.94 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| Mil-Spec | Yes |
| REACH SVHC Compliance Edition | 2016/06/20 |
| ECCN Code | EAR99 |
