DCR010505U - TI
Manufacturer:
TI
ManyChip's Part#:
MC769883
Category:
DC to DC Converter
Package:
SOP-28
Datasheet:
Datasheet 3D Model
Description:
Isolated Board Mount DC-DC Converter, Surface Mount DIP, Fixed, SMD, 1W, 5V, 200mA
Stock Locations:
Availability:
1,513 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 8.03

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The DCR010505U is a 1-output board-mount isolated Regulated DC to DC Converter giving standard JEDEC outlines suitable for high-volume assembly. The DCR01 series 1W converter offers very low output noise, high reliability and high accuracy.
1000Vrms Isolation
Device-to-device synchronization
3.3W/cm³ Power density
Thermal protection
Short-circuit protection
High efficiency

Show

DCR010505U Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	12 Pin
Case/Package	SOP-28
Frequency	800 kHz
Supply Voltage (DC)	4.50V (min)
Number of Outputs	1 Output
Input Voltage (DC)	5.00 V
Output Voltage	5 V
Output Current	0.2 A
Quiescent Current	25.0 mA
Number of Regulated Outputs	1 Output
Output Power	1 W
Isolation Voltage	1 kV
Switching Frequency	400 kHz
Input Voltage (Max)	5.5 V
Input Voltage (Min)	4.5 V
Input Voltage (DC Max)	5.5 V
Input Voltage (DC Min)	4.5 v
Output Current (Max)	200 mA
Output Current (Min)	0.2 A
Input Power (Max)	1 W
Input Power (Max)	1 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	4.5V ~ 5.5V
	Show
Size-Length	17.9 mm
Size-Width	10.33 mm
Size-Height	2.3 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/12/17
