Description
- The DRV8801AQRMJRQ1 is a 2.8A automotive brushed DC Motor Driver with current sense provides a versatile motor-driver solution with a full H-bridge driver. The device can drive a brushed DC motor or one winding of a stepper motor, as well as other devices like solenoids. A simple PHASE and ENABLE interface allows easy interfacing to controller circuits. The output stages use N-channel power MOSFETs configured as an H-bridge. The DRV8801A device is capable of peak output currents up to ±2.8A and operating voltages up to 36V. An internal charge pump generates required gate drive voltages. A low-power sleep mode is provided which shuts down internal circuitry to achieve very low quiescent current draw. This sleep mode can be set using a dedicated nSLEEP pin. Internal protection functions are provided under-voltage lockout, over-current protection, short-to-supply protection, short-to-ground protection, over-temperature warning and over-temperature shutdown.
- Low ON-resistance 0.83R outputs
- Low-power sleep mode
- 100% PWM Supported
- Configurable over-current limit
- VBB under-voltage lockout (UVLO) protection
- Over-current Protection (OCP) protection
- Short-to-supply protection
- Short-to-ground protection
- Over-temperature Warning (OTW) protection
- Over-temperature Shutdown (OTS) protection
- Over-current and Over-temperature Fault Conditions Indicated On Pin (nFAULT) protection
- Green product and no Sb/Br
- This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
DRV8801AQRMJRQ1 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 16 Pin |
| Case/Package | WQFN-16 |
| Supply Voltage (DC) | 6.50V (min) |
| Number of Outputs | 1 Output |
| Output Current | 2.8 A |
| Number of Positions | 16 Position |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 6.5V ~ 36V |
| Supply Voltage (Max) | 36 V |
| Supply Voltage (Min) | 6.5 V |
| Show | |
| Operating Temperature | -40℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Cut Tape (CT) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
| ECCN Code | EAR99 |
