Description

The DSN6NZ81H103Q55B is a compact high-performance lead type EMI suppression Power Line Filter which can be mounted 2.54mm pitch. Its three terminal structure enables precise high frequency performance.
REACH compliant
10000pF Capacitance
-25 to 85°C Operating temperature range
Leaded 3 terminal capacitors

Show

DSN6NZ81H103Q55B Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Case/Package	*
Pin Pitch	2.50 mm
Voltage Rating (DC)	50.0 V
Operating Voltage	50 V
Current Rating	6 A
Capacitance	10000 pF
Shielding	No
Ripple Current	6000 mA
Current Rating (Max)	6 A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-25 ℃
Voltage Rating (Max)	50 VDC
Voltage Rating	50 V
	Show
Size-Length	7 mm
Size-Width	2.54 mm
Size-Height	8 mm
Operating Temperature	-25℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
