Image is for your reference only,please check specifications for details

FCPF400N80Z - Fairchild
Manufacturer:
Fairchild
ManyChip's Part#:
MC13478268
Category:
High Voltage MOS Transistor
Package:
TO-220F-3
Datasheet:
Datasheet 3D Model
Description:
FAIRCHILD SEMICONDUCTOR FCPF400N80Z Power MOSFET, N Channel, 11A, 800V, 0.34Ω, 10V, 4.5V
Stock Locations:
Availability:
2,161 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.91

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The FCPF400N80Z is a N-channel SuperFET® II high voltage super-junction MOSFET utilizes charge balance technology for outstanding low ON-resistance and lower gate charge performance. This technology is tailored to minimize conduction loss, provide superior switching performance, dV/dt rate and higher avalanche energy. Consequently, SuperFET II MOSFET is very suitable for the switching power applications such as PFC, server/telecom power, FPD TV power, ATX power and industrial power applications.
Ultra low gate charge (Qg = 43nC)
Low effective output capacitance (Coss.eff = 138pF)
100% avalanche tested

Show

FCPF400N80Z Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220F-3
Power Rating	35.7 W
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	0.34 Ω
Polarity	N-Channel
Power Dissipation	35.7 W
Threshold Voltage	4.5 V
Drain to Source Voltage (Vds)	800 V
Continuous Drain Current (Ids)	14A
Rise Time	12 ns
Input Capacitance (Ciss)	2350pF @100V(Vds)
Fall Time	2.6 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	35.7W (Tc)
	Show
Size-Length	10.36 mm
Size-Width	4.9 mm
Size-Height	16.07 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Rail, Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
HK STC License	NLR
