Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 8 Pin |
Case/Package | SOIC-8 |
Voltage Rating (DC) | 60.0 V |
Current Rating | 12.0 A |
Number of Positions | 8 Position |
Drain to Source Resistance (on) (Rds) | 0.0088 Ω |
Polarity | N-Channel |
Power Dissipation | 2.5 W |
Threshold Voltage | 4 V |
Input Capacitance | 2.20 nF |
Gate Charge | 34.0 nC |
Drain to Source Voltage (Vds) | 60 V |
Breakdown Voltage (Drain to Source) | 60.0 V |
Breakdown Voltage (Gate to Source) | ±20.0 V |
Continuous Drain Current (Ids) | 12.0 mA |
Rise Time | 20 ns |
Input Capacitance (Ciss) | 2200pF @25V(Vds) |
Input Power (Max) | 2.5 W |
Fall Time | 14 ns |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -55 ℃ |
Power Dissipation (Max) | 2.5 W |
Show | |
Size-Length | 5 mm |
Size-Width | 4 mm |
Size-Height | 1.5 mm |
Operating Temperature | -55℃ ~ 150℃ (TJ) |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/06/15 |
ECCN Code | EAR99 |
