Description
- Optoisolator Output Channel
FODM3063 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 4 Pin |
| Case/Package | Mini-Flat |
| Output Current | 0.07 A |
| Number of Channels | 1 Channel |
| Number of Positions | 4 Position |
| Forward Voltage | 1.5V (Max) |
| Power Dissipation | 300 mW |
| Isolation Voltage | 3750 Vrms |
| Holding Current | 300 µA |
| Forward Current | 60 mA |
| Output Voltage (Max) | 420 VAC |
| Input Current (Min) | 60 mA |
| Reverse Breakdown Voltage | 6 V |
| Maximum Forward Voltage (Max) | 1.5 V |
| Forward Current (Max) | 60 mA |
| Operating Temperature (Max) | 100 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 300 mW |
| Show | |
| Size-Length | 3.85 mm |
| Size-Width | 4.4 mm |
| Size-Height | 2.2 mm |
| Operating Temperature | -40℃ ~ 100℃ |
| Product Lifecycle Status | Active |
| Packaging | Box |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
