HMC397 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC39554104
Category:
Amplifier chip
Package:
Die
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES HMC397 RF Amplifier IC, 15dB Gain / 6dB Noise, DC to 10GHz, 5V, Gel Pack
Stock Locations:
Availability:
225 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 15.68

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Product Details
The HMC397 die is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) Gain Block MMIC DC to 10 GHz amplifier. This amplifier can be used as either a cascadable 50 Ohm gain stage or to drive the LO of HMC mixers with up to +16 dBm output power. The HMC397 offers 15 dB of gain and an output IP3 of +32 dBm while requiring only 56 mA from a +5V supply.
The Darlington feedback pair used results in reduced sensitivity to normal process variations and yields excellent gain stability over temperature while requiring a minimal number of external bias components. The HMC397 can easily be integrated into Multi- Chip-Modules (MCMs) due to its small (0.22mm²) size. All data is with the chip in a 50 Ohm test fixture connected via 0.025mm (1 mil) diameter wire bonds of minimal length 0.5mm (20 mils).
Applications
Microwave & VSAT Radios
Test Equipment
Military EW, ECM, C³I
Space Telecom
### Features and Benefits
Gain: 15 dB
P1dB Output Power: +15 dBm
Stable Gain Over Temperature
50 Ohm I/O’s
Small Size: 0.38 x 0.58 x 0.1 mm

Show

HMC397 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	Die
Frequency	0Hz ~ 10GHz
Supply Voltage (DC)	5.00V (max)
Supply Current	56 mA
Power Dissipation	339 mW
Gain	15 dB
Test Frequency	10 GHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	339 mW
Supply Voltage	5 V
Supply Voltage (Max)	5 V
	Show
Operating Temperature	-55℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
