Image is for your reference only,please check specifications for details

HMC434E - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC2814303
Category:
RF Module, IC, Accessory
Package:
SOT-26-6
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES HMC434E Special Function IC, RF Frequency Divider, GaAs HBT MMIC, DC to 8GHz, 2.7V to 3.3V, SOT-26-6
Stock Locations:
Availability:
1,627 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 15.85

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The HMC434E is a Low Noise Divide-by-8 Static Divider utilizes InGaP GaAs HBT technology. This device operates from DC (with a square wave input) to 8GHz input frequency with a single +3V DC supply. Single-ended inputs and outputs reduce component count and cost. The low additive SSB phase noise of -150dBc/Hz at 100kHz offset helps the user maintain good system noise performance. This is ideal for DC to C band PLL applications and cellular/3G infrastructure.
Ultra low SSB phase noise (-150dBc/Hz)
Single-ended I/O"s
-2dBm Output power
Single DC supply (+3V at 62mA)
ESD sensitive device, take proper precaution while handling the device.

Show

HMC434E Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	SOT-26-6
Frequency	0Hz ~ 8GHz
Supply Voltage (DC)	2.70V (min)
Supply Current	62 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	3.3 V
Supply Voltage (Min)	2.7 V
	Show
Size-Length	3 mm
Size-Width	1.7 mm
Size-Height	1.3 mm
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	3A001.a.11.b
