Description

The HMC520LC4 is a compact GaAs I/Q MMIC Mixer which operates between 6 to 10GHz. Mixer which can be used as either an image reject mixer or a single sideband up-converter. The mixer utilizes two standard Hittite double balanced mixer cells and a 90 degree hybrid fabricated in a GaAs MESFET process. A low frequency quadrature hybrid was used to produce a 100MHz USB IF output. This product is a much smaller alternative to hybrid style Image reject mixers and single sideband up-converter assemblies. The HMC520LC4 eliminates the need for wire bonding allowing use of surface mount manufacturing techniques.
DC to 3.5GHz Wide IF bandwidth
40dB Image rejection
50dB LO to RF isolation
23dBm High input IP3

Show

HMC520LC4 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Number of Pins	24 Pin
Case/Package	TFQFN-24
Frequency	6GHz ~ 10GHz
Power Dissipation	508 mW
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	508 mW
	Show
Product Lifecycle Status	End of Life
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
