Description

Product Details
The HMC554ALC3B is a general purpose double balanced mixer in a leadless RoHS compliant SMT package that can be used as an upconverter or downconverter between 11 and 20 GHz. This mixer is fabricated in a GaAs MESFET process, and requires no external components or matching circuitry. The HMC554ALC3B provides excellent LO to RF and LO to IF isolation due to optimized balun structures. The RoHS compliant HMC554ALC3B eliminates the need for wire bonding, and is compatible with high volume surface mount manufacturing techniques.
**Applications**
Point-to-Point Radios
Point-to-Multi-Point Radios & VSAT
Test Equipment & Sensors
Military End-Use
### Features and Benefits
High LO/RF Isolation: 46 dB
Passive Double Balanced Topology
Low Conversion Loss: 7 dB
Wide IF Bandwidth: DC - 6 GHz
Robust 1,000V ESD, Class 1C
12 Lead Ceramic 3x3mm SMT Package: 9mm2

Show

HMC554ALC3B Specifications
