Description

The IRL640PBF is a third generation N-channel enhancement-mode Power MOSFET comes with the best combination of fast switching, ruggedized device design and low ON-resistance. The package is universally preferred for power dissipation levels to approximately 50W. The low thermal resistance of the package contributes to its wide acceptance throughout the industry.
Dynamic dV/dt rating
Repetitive avalanche rated
Logic-level gate drive
Ease of paralleling
RDS (ON) Specified at VGS = 4 and 5V
Simple drive requirements

Show

IRL640PBF Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Voltage Rating (DC)	200 V
Current Rating	17.0 A
Power Rating	125 W
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	0.18 Ω
Polarity	N-Channel
Power Dissipation	125 W
Threshold Voltage	2 V
Drain to Source Voltage (Vds)	200 V
Breakdown Voltage (Drain to Source)	200 V
Continuous Drain Current (Ids)	17.0 A
Rise Time	83.0 ns
Input Capacitance (Ciss)	1800pF @25V(Vds)
Input Power (Max)	125 W
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	125000 mW
	Show
Size-Length	10.41 mm
Size-Width	4.7 mm
Size-Height	9.01 mm
Product Lifecycle Status	Active
Packaging	Tube
Minimum Packing Quantity	50
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
