Description
- Benefits:
- Optimized for Logic Level Drive
- Improved Gate, Avalanche and Dynamic dv/dt Ruggedness
- Fully Characterized Capacitance and Avalanche SOA
- Enhanced body diode dv/dt and di/dt Capability
- Lead-Free, RoHS Compliant
- StrongIRFET™
IRL7472L1TRPBF Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 15 Pin |
| Case/Package | Direct-FET |
| Number of Positions | 11 Position |
| Drain to Source Resistance (on) (Rds) | 0.00034 Ω |
| Polarity | N-Channel |
| Power Dissipation | 341 W |
| Threshold Voltage | 1.7 V |
| Drain to Source Voltage (Vds) | 40 V |
| Continuous Drain Current (Ids) | 59A |
| Rise Time | 176 ns |
| Input Capacitance (Ciss) | 20082pF @25V(Vds) |
| Fall Time | 137 ns |
| Operating Temperature (Max) | 175 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 3.8W (Ta), 341W (Tc) |
| Show | |
| Size-Length | 9.15 mm |
| Size-Width | 7.1 mm |
| Size-Height | 0.74 mm |
| Material | Silicon |
| Operating Temperature | -55℃ ~ 175℃ (TJ) |
| Product Lifecycle Status | Unknown |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
