Image is for your reference only,please check specifications for details

L6920DB - ST Microelectronics
Manufacturer:
ST Microelectronics
ManyChip's Part#:
MC126413427
Category:
Voltage Regulator
Package:
MSOP-8
Datasheet:
Datasheet 3D Model
Description:
Conv DC-DC 0.8V to 5.5V Step Up Single-Out 1.8V to 5.2V/3.3V/5V 8Pin MSOP Tube
Stock Locations:
Availability:
1,224 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.58

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Boost Switching Regulator IC Positive Adjustable (Fixed) 1.8V (3.3V, 5V) 1 Output 800mA (Switch) 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)

Show

L6920DB Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Frequency	1 MHz
Number of Outputs	1 Output
Output Voltage	1.8.5.2 V
Output Current	500 mA
Number of Positions	8 Position
Switching Frequency	1 MHz
Input Voltage (Max)	5.5 V
Input Voltage (Min)	800 mV
Output Voltage (Max)	5.2 V
Output Voltage (Min)	1.8 V
Operating Temperature (Max)	150 ℃
Input Voltage	0.6V ~ 5.5V
	Show
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
