Image is for your reference only,please check specifications for details
- LC1D098P7 - Schneider Electric
-
Manufacturer:Schneider Electric
-
ManyChip's Part#:MC186762454
-
Category:Signal Relays
-
Datasheet:Datasheet 3D Model
-
Description:SCHNEIDER ELECTRIC / TELEMECANIQUE LC1D098P7 Контактор, 230 В AC, 4 полюса, 2 NO / 2 NC, DIN-рейка, 20 А, 230 В
-
Stock Locations:
-
Availability:15 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 61.72
Updated at 31/10/2026 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- LC1D098P7 — это 4-полюсный контактор TeSys D с AC-катушкой. Компоновка контактных полюсов: 2 NO – 2 NC для питания; 1 NO – 1 NC для вспомогательных контактов с защитным кожухом. Без встроенного модуля подавления помех. Контактор типа зеркального контакта (1 NC), соответствующий стандарту IEC 60947-4-1, а также механически связанный тип (1 NO – 1 NC), соответствующий стандарту IEC 60947-5-1. Контактор TeSys D обеспечивает быструю и простую установку, сохраняя компактные размеры 45 и 55 мм (для токов от 40 до 65 А) и соответствует международным стандартам. Версии от 40 до 65 А оснащены технологией EverLink — новой запатентованной терминальной технологией, которая гарантирует постоянное качество затяжки даже при проседании проводников.
- Применение контактора для резистивных нагрузок
- Мощность рассеивания: 1,56 Вт AC-1
LC1D098P7 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | DIN Rail |
| Operating Voltage | 230 VAC |
| Contact Current Rating | 20 A |
| Coil Voltage | 230 VAC |
| Coil Voltage (AC) | 230 V |
| Coil Voltage (DC) | 110 V |
| Operating Temperature (Max) | 60 ℃ |
| Operating Temperature (Min) | -5 ℃ |
| Show | |
| Size-Length | 85 mm |
| Size-Width | 45 mm |
| RoHS | Non-Compliant |
| REACH SVHC Compliance | No SVHC |
