LM78L05ACZX - Fairchild
Manufacturer:
Fairchild
ManyChip's Part#:
MC11462171
Category:
Voltage Regulator
Package:
TO-226-3
Datasheet:
Datasheet 3D Model
Description:
FAIRCHILD SEMICONDUCTOR LM78L05ACZX Linear Voltage Regulator, Fixed, 10V to 30V input, 5V/100mA out, TO-92-3
Stock Locations:
Availability:
9,513 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.32

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The LM78L05ACZX is a monolithic fixed Positive Voltage Regulator suitable for application that required supply current up to 100mA.
Thermal overload protection
Short circuit protection
Output voltage offered in ±5% tolerance

Show

LM78L05ACZX Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-226-3
Operating Voltage	8V ~ 20V
Current Rating	100 mA
Number of Outputs	1 Output
Input Voltage (DC)	30.0V (max)
Output Voltage	5 V
Output Current	100 mA
Number of Positions	3 Position
Power Dissipation	750 W
Quiescent Current	2 mA
voltage rating	1.7V @40mA
Input Voltage (Max)	30 V
Input Voltage (Min)	10 V
Output Voltage (Max)	5 V
Output Current (Max)	0.1 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	750 mW
Accuracy	±5 %
Supply Voltage (Min)	7 V
Input Voltage	≤30 V
	Show
Size-Length	5.2 mm
Size-Width	3.86 mm
Size-Height	4.58 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
HTS Code	8542390000
ECCN Code	EAR99
