Description
- The LMR23625-Q1 SIMPLE SWITCHER® is an easy to use 36 V, 2.5 A synchronous step down regulator. With a wide input range from 4 V to 36 V, it is suitable for various applications from industrial to automotive for power conditioning from unregulated sources. Peak current mode control is employed to achieve simple control loop compensation and cycle-by-cycle current limiting. A quiescent current of 75 µA makes it suitable for battery powered systems. Internal loop compensation means that the user is free from the tedious task of loop compensation design. This also minimizes the external components. The device has option for fixed frequency FPWM mode to achieve small output voltage ripple at light load. An extended family is available in 1 A (LMR23610-Q1), 1.5 A (LMR23615-Q1) and 3 A (LMR23630-Q1) load current options in pin-to-pin compatible packages which allows simple, optimum PCB layout. A precision enable input allows simplification of regulator control and system power sequencing. Protection features include cycle-by-cycle current limit, hiccup mode short circuit protection and thermal shutdown due to excessive power dissipation.
LMR23625CFQDDARQ1 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | SOIC-8 |
| Number of Outputs | 1 Output |
| Output Voltage | 1V ~ 28V |
| Output Current | 2.5 A |
| Switching Frequency | 2.1 MHz |
| Switching Current | 4.8 A |
| Input Voltage (Max) | 36 V |
| Input Voltage (Min) | 4.5 V |
| Output Voltage (Max) | 28 V |
| Output Voltage (Min) | 1 V |
| Output Current (Max) | 2.5 A |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Show | |
| Operating Temperature | -40℃ ~ 125℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
