LMZ34002RKGT - TI
Manufacturer:
TI
ManyChip's Part#:
MC1427200
Category:
DC to DC Converter
Package:
QFN-41
Datasheet:
Datasheet 3D Model
Description:
DC-DC POL Converter, Adjustable, Buck, Boost, 900kHz, 4.5V to 40Vin, -17V to -3Vout, 2A, QFN-41
Stock Locations:
Availability:
261 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 85.06

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The LMZ34002RKGT is a SIMPLE SWITCHER® 4.5 to 40V 2A negative output Power Module that combines a 15W DC/DC converter with a shielded inductor. This total power solution allows as few as five external components and eliminates the loop compensation and magnetics part selection process. The LMZ34002 offers the flexibility and the feature-set of a discrete design and is ideal for powering a wide range of ICs and analogue circuits requiring a negative output voltage.
Complete integrated power solution allows small footprint, low-profile design
Synchronizes to an external clock
Adjustable slow-start
Programmable under-voltage lockout (UVLO)
Output over-current protection
Over-temperature protection
14°C/W Enhanced thermal performance
Meets EN55022 Class B emissions
Integrated shielded inductor
Green product and no Sb/Br
ESD sensitive device, take proper precaution while handling the device.
