Image is for your reference only,please check specifications for details
- LMZ34202RVQR - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC85398817
-
Category:DC-DC Converters
-
Package:QFN-43
-
Datasheet:Datasheet 3D Model
-
Description:Модуль переключения напряжений DC-DC с выходом 2,5 В до 7,5 В и 2 А, 43 контакта, тип канала QFN T/R
-
Stock Locations:
-
Availability:243 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 20.26
Updated at 31/10/2026 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Неизолированный модуль переключения напряжений DC-DC с одним выходом, напряжение входа 2,5 ~ 7,5 В, выходное напряжение 2 А, напряжение ввода от 4,5 В до 42 В
LMZ34202RVQR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 43 Pin |
| Case/Package | QFN-43 |
| Number of Outputs | 1 Output |
| Output Voltage | 2.5V ~ 7.5V |
| Output Current | 2 A |
| Number of Regulated Outputs | 1 Output |
| Switching Frequency | 300kHz ~ 1000kHz |
| Input Voltage (Max) | 42 V |
| Input Voltage (Min) | 4.5 V |
| Output Current (Max) | 2 A |
| Operating Temperature (Max) | 105 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Input Voltage | 4.5V ~ 42V |
| Show | |
| Size-Height | 4.35 mm |
| Operating Temperature | -40℃ ~ 105℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
Order guide
-
TT in advance (bank transfer), Western Union, Credit card,
PayPal. Customer is responsible for shipping fee, bank
charges, duties and taxes.
-
- You can choose whether shipping charges will be charged through your shipping account or by us.
- Please confirm with the logistics company in advance for remote areas.
(Additional charges ($35-$50) may apply for delivery in these areas)
- Delivery date: usually 2 to 7 working days.
- A tracking number will be sent after your order ships.
- - Carefully inspected and packed by ManyChip warehouse - Vacuum packaging - Anti-static packaging - Shockproof foam
- The terms here are for reference only, the actual terms are subject to the sales quotation. - Please confirm product specifications when ordering. - MOQ refers to the minimum order quantity required to purchase each part. - If you have special ordering instructions, please indicate them on the ordering page. - Inspection (PSI) will be performed prior to shipment.
- - Income Quality Control (IQC), 1000+ qualified dealers. - Chips are tested by authoritative organizations to ensure the quality, authenticity and safety of your device. - Decapsulation control - X-ray control - XRF inspection - Electrical testing - Surface testing -Digital components warehouse, covering an area of 800 square meters, with constant temperature and humidity
