MAX1239EEE+ - Maxim Integrated
Manufacturer:
Maxim Integrated
ManyChip's Part#:
MC42077169
Category:
Analog to Digital, ADC IC
Package:
QSOP-16
Datasheet:
Datasheet 3D Model
Description:
2.7V to 3.6V and 4.5V to 5.5V, Low-Power, 4-/12Channel, 2-Wire Serial, 12Bit ADCs
Stock Locations:
Availability:
433 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 20.2

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The MAX1239 low-power, 12-bit, multichannel analog-to-digital converters (ADCs) feature internal track/hold (T/H), voltage reference, clock, and an I 2C-compatible 2-wire serial interface. These devices operate from a single supply of 2.7V to 3.6V and require only 670µA at the maximum sampling rate of 94.4ksps. Supply current falls below 230µA for sampling rates under 46ksps. AutoShutdown™ powers down the devices between conversions, reducing supply current to less than 1µA at low throughput rates.
High-Speed I2C-Compatible Serial Interface
Single-Supply
Internal Reference 2.048V
External Reference: 1V to Vdd
Internal Clock
12-Channel Single-Ended or 6-Channel Fully Differential
Internal FIFO with Channel-Scan Mode
Software-Configurable Unipolar/Bipolar

Show

MAX1239EEE+ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	QSOP-16
Supply Voltage (DC)	2.70V (min)
Operating Voltage	2.7V ~ 3.6V
Supply Current	900 µA
Number of Circuits	1 Circuit
Number of Channels	12 Channel
Number of Positions	16 Position
Number of Bits	12 Bit
Power Dissipation	2 mW
Sample Rate	94.4 ksps
Number of ADCs	12 ADC
Number of Inputs	6, 12 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	666.7 mW
Number of Input Channels	12 Channel
Supply Voltage	2.7V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	2.7 V
	Show
Size-Length	4.98 mm
Size-Width	3.99 mm
Size-Height	1.55 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
