- MAX306EWI - Maxim Integrated
-
Manufacturer:Maxim Integrated
-
ManyChip's Part#:MC63216503
-
Category:Multiplexer IC
-
Package:SOIC-16
-
Datasheet:Datasheet 3D Model
-
Description:Multiplexer Switch ICs Precision, 16Channel/Dual 8Channel, High-Performance, CMOS Analog Multiplexers
-
Stock Locations:
-
Availability:288 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 10.2
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- General Description
- The MAX306/MAX307 precision, monolithic, CMOS analog multiplexers (muxes) offer low on-resistance (less than 100Ω), which is matched to within 5Ω between channels and remains flat over the specified analog signal range (7Ω, max). They also offer low leak age over temperature (INO(OFF)less than 2.5nA at +85°C) and fast switching speeds (tTRANSless than 250ns). The MAX306 is a single-ended 1-of-16 device, and the MAX307 is a differential 2-of-8 device.
- Features
- ♦Guaranteed On-Resistance Match Between Channels, <5ΩMax
- ♦Low On-Resistance, <100ΩMax
- ♦Guaranteed Flat On-Resistance over Specified Signal Range, 7ΩMax
- ♦Guaranteed Charge Injection, <10pC
- ♦INO(OFF)Leakage <2.5nA at +85°C
- ♦ICOM(OFF)Leakage <20nA at +85°C
- ♦ESD Protection >2000V
- ♦Plug-In Upgrade for Industry-Standard DG406/DG407/DG506A/DG507A
- ♦Single-Supply Operation (+5V to +30V)
- Bipolar-Supply Operation (±4.5V to ±20V)
- ♦Low Power Consumption, <1.25mW
- ♦Rail-to-Rail Signal Handling
- ♦TTL/CMOS-Logic Compatible
- Applications
- Sample-and-Hold
- Circuits
- Test Equipment
- Heads-Up Displays
- Guidance and Control Systems
- Military Radios
- Communications Systems
- Battery-Operated Systems
- PBX, PABX
- Audio Signal Routing
MAX306EWI Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 28 Pin |
| Case/Package | SOIC-16 |
| Supply Current | 75.0 µA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 16 Channel |
| Power Dissipation | 1000 mW |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | 40 ℃ |
| Power Dissipation (Max) | 1000 mW |
| Supply Voltage (Max) | 30 V |
| Supply Voltage (Min) | 5 V |
| Show | |
| Size-Length | 18.1 mm |
| Size-Width | 7.6 mm |
| Size-Height | 2.35 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Unknown |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
