Description
- General Description
- The MIC4680 SuperSwitcher™ is an easy-to-use fixed or adjustable output voltage step-down (buck) switch-mode voltage regulator. The 200kHz MIC4680 achieves up to 1.3A of continuous output current over a wide input range in a 8-pin SOIC.
- Features
- • SOIC-8 package with up to 1.3A output current
- • All surface mount solution
- • Only 4 external components required
- • Fixed 200kHz operation
- • 3.3V, 5V, and adjustable output versions
- • Internally compensated withfast transient response
- • Wide 4V to 34V operating input voltage range
- • Less than 2µA typical shutdown-mode current
- • Up to 90% efficiency
- •Thermal shutdown
- •Overcurrent protection
MIC4680BM Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | SOIC-8 |
| Supply Voltage (DC) | 34.0V (max) |
| Number of Outputs | 1 Output |
| Output Voltage | 5.00 V |
| Output Current | 1.3 A |
| Switching Frequency | 200 kHz |
| Topology | Buck |
| Input Voltage | 4V ~ 34V |
| Show | |
| Operating Temperature | -40℃ ~ 125℃ |
| Product Lifecycle Status | Obsolete |
| Packaging | Bulk |
| RoHS | Non-Compliant |
