Description

The MJD44H11G is a bipolar Power Transistor, designed for general purpose power and switching output or driver stages in applications such as switching regulators, converters and power amplifiers.
Lead formed for surface mount application in plastic sleeves (no suffix)
Straight lead version in plastic sleeves
Electrically similar to popular D44H/D45H series
Low collector-emitter saturation voltage
Fast switching speeds
Complementary pairs simplifies designs
AEC-Q101 Qualified
PPAP capable

Show

MJD44H11G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	TO-252-3
Frequency	85 MHz
Voltage Rating (DC)	80.0 V
Current Rating	8.00 A
Halogen Free Status	Halogen Free
Number of Positions	3 Position
Polarity	NPN
Power Dissipation	20 W
Breakdown Voltage (Collector to Emitter)	80 V
Thermal Resistance	6.25℃/W (RθJC)
Continuous Collector Current	8A
hFE Min	40 @4A, 1V
Input Power (Max)	1.75 W
DC Current Gain (hFE)	60
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	1750 mW
	Show
Size-Length	6.73 mm
Size-Width	6.22 mm
Size-Height	2.38 mm
Material	Silicon
Operating Temperature	-55℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
