Image is for your reference only,please check specifications for details
- MKV58F1M0VLQ24 - NXP
-
Manufacturer:NXP
-
ManyChip's Part#:MC86845861
-
Category:Microcontroller, MCU IC
-
Package:LQFP-144
-
Datasheet:Datasheet 3D Model
-
Description:MCU 32Bit ARM Cortex M7 RISC 1Mb Flash 1.8V/2.5V/3.3V 144Pin LQFP Tray
-
Stock Locations:
-
Availability:0 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Overview
- The Kinetis® KV5x family of MCU is a high-performance solution offering exceptional precision, sensing and control targeting industrial motor control, industrial drives and automation and power conversion applications. The Kinetis KV5x MCU is built on the Arm® Cortex®-M7 core running at 240 MHz with single precision floating point unit. It features high-resolution pulse-width modulation (PWM) with 260 picosecond resolution, 4x 12-bit analog-to-digital converters (ADCs) sampling at 5 mega samples per second (MS/s), 3 FlexCAN modules, optional Ethernet communications and comprehensive enablement suite from NXP® and third-party resources including reference designs, software libraries and motor configuration tools.
- MoreLess
- ## Features
- * High-performance 240 MHz Arm® Cortex®-M7 core combined with a high level of analog and digital integration targeted at real-time control applications
- * Up to 1 MB Flash and 256 KB RAM, 16 KB instruction cache and 8 KB data cache. 256 KB of RAM includes 64 KB of ITCM RAM ensuring maximum CPU performance of fast control loops with minimal latency
- * 64-bit AXI memory interface with I-Cache and D-Cache – efficient access to external resources; interface to large external memories for a complete RTOS experience; support for richer HMI with higher resolution graphics, multiple connectivity stacks and middleware
- * 4 x 8ch 12-bit ADC’s sampling at 5 MSPS with dual sample and hold circuitry, can capture current and voltage simultaneously for two motors giving true independent dual motor control
- * Ethernet option with True Random Number Generator and Cryptographic unit providing a low cost integrated connectivity solution
- * 2 eFlexPWM blocks provides 4 independent time bases per module with a highly flexible configuration that easily supports motor and power control topologies
- * Multiple instantiations of timer blocks provide a vast array of timers (44 channels) simplifying the complex task of advanced motor control
- * A single eFlexPWM block featuring 12 channels with Nano-Edge capability, providing up to 260pSec resolution on pulse width and frequency modulation
- * Up to 3 FlexCAN modules—High speed, high-reliability industrial communication
- * Inter-peripheral cross bar, with And or Invert Logic, provides a highly flexible connection fabric between peripherals that supports simplified control topology implementation
- ## Features
MKV58F1M0VLQ24 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 144 Pin |
| Case/Package | LQFP-144 |
| Frequency | 240 MHz |
| Number of Positions | 144 Position |
| RAM Memory Size | 256 KB |
| Number of Bits | 32 Bit |
| Number of ADCs | 4 ADC |
| Number of Inputs and Outputs | 111 Input IO |
| Operating Temperature (Max) | 105 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Number of DACs | 1 DAC |
| Supply Voltage (Max) | 3.6 V |
| Supply Voltage (Min) | 1.71 V |
| Show | |
| Operating Temperature | -40℃ ~ 105℃ |
| Product Lifecycle Status | Active |
| Packaging | Tray |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
