Description

Change state in a high power transistor by implementing this NCP5901MNTBG power driver by ON Semiconductor. This device has a maximum propagation delay time of 35 ns. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This gate driver has a minimum operating temperature of -10 °C and a maximum of 125 °C. This device has a minimum operating supply voltage of 4.5 V and a maximum of 13.2 V.

Show

NCP5901MNTBG Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	DFN-8
Rise/Fall Time	16ns, 11ns
Halogen Free Status	Halogen Free
Number of Outputs	2 Output
Output Voltage	35 V
Number of Positions	8 Position
Rise Time	16 ns
Fall Time	11 ns
Fall Time (Max)	27 ns
Fall Time (Max)	35 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-10 ℃
Supply Voltage	4.5V ~ 13.2V
Supply Voltage (Max)	13.2 V
Supply Voltage (Min)	4.5 V
	Show
Size-Length	2 mm
Size-Width	2 mm
Size-Height	0.95 mm
Operating Temperature	0℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2018/06/27
ECCN Code	EAR99
