Description

This NUD3124DMT1G specialized power IC manufactured by ON Semiconductor will exceed your power needs. This USB PWM controller has a minimum operating temperature of -40 °C and a maximum of 125 °C.

Show

NUD3124DMT1G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	SC-70-6
Supply Voltage (DC)	12.0V (min)
Operating Voltage	12.0V (max)
Halogen Free Status	Halogen Free
Number of Outputs	2 Output
Output Voltage	28 V
Output Current	200 mA
Number of Channels	2 Channel
Drain to Source Resistance (on) (Rds)	800 mΩ
Power Dissipation	380 mW
Drain to Source Voltage (Vds)	28.0 V
Breakdown Voltage (Drain to Source)	28 V
Continuous Drain Current (Ids)	150 mA
Rise Time	708 ns
Output Current (Max)	150 mA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	28 V
Supply Voltage (Min)	12 V
	Show
Size-Length	3 mm
Size-Width	1.5 mm
Size-Height	0.94 mm
Operating Temperature	-40℃ ~ 125℃ (TA)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
