Image is for your reference only,please check specifications for details

OP11EPZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC534633
Category:
Operational Amplifier, OP Amp IC
Package:
DIP-14
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES OP11EPZ Operational Amplifier, Quad, 4 Amplifier, 3MHz, 1V/µs, ± 5V to ± 15V, DIP, 14Pins
Stock Locations:
Availability:
244 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 14.38

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The OP11EPZ is a quad matched 741-type Operational Amplifier for use in designs requiring minimum space and cost while maintaining performance. The OP11 is pin compatible with the LM148, LM348, RM4156, RM4158 and HA4741 amplifiers. The amplifier is matched for common-mode rejection ratio and offset voltage, which is very important in designing instrumentation amplifiers. In addition, the amplifier is designed to have equal positive-going and negative-going slew rates, which is an important consideration for good audio system performance.
Low noise
Silicon-nitride passivation
Internal frequency compensation
Low crossover distortion
Continuous short-circuit protection
Low input bias current
94dB Minimum guaranteed matched CMRR
750µV Maximum guaranteed matched VOS

Show

OP11EPZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	14 Pin
Case/Package	DIP-14
Number of Circuits	4 Circuit
Number of Channels	4 Channel
Number of Positions	14 Position
Common Mode Rejection Ratio	100 dB
Bandwidth	3 MHz
Slew Rate	1.00 V/μs
Input Offset Voltage	300 µV
Input Bias Current	180 nA
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Minimum CMRR Range	100 dB
Supply Voltage (Max)	15 V
	Show
Size-Length	19.05 mm
Size-Width	6.35 mm
Size-Height	3.3 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
