OPA567AIRHGT - TI
Manufacturer:
TI
ManyChip's Part#:
MC6093000
Category:
Operational Amplifier, OP Amp IC
Package:
VQFN-12
Datasheet:
Datasheet 3D Model
Description:
TEXAS INSTRUMENTS OPA567AIRHGT Operational Amplifier, Single, 1 Amplifier, 1.2MHz, 1.2V/µs, 2.7V to 5.5V, QFN, 12Pins
Stock Locations:
Availability:
78 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 4.7

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The OPA567AIRHGT is a single high-current Operational Amplifier with rail-to-rail input and output. It is designed for driving a wide variety of loads while operating on low-voltage supplies. It operates from single supplies for design flexibility and has rail-to-rail swing on the input and output. Output swing is within 300mV of the supply rails, with output current of 2A. Smaller loads allow an output swing closer to the rails. The OPA567 is unity gain stable, easy to use and free from the phase inversion problems found in some power amplifier. High performance is maintained at voltage swings near the output rails. The OPA567 provides an accurate user-selected current limit set with an external resistor or digitally adjusted via a digital-to-analog converter (DAC). The output of the OPA567 can be independently disabled using the enable pin, saving power and protecting the load. Two flags are provided. The current limit flag, IFLAG, warns of current limit conditions.
Thermal protection
Adjustable current limit
Two flags - Current limit and temperature warning
Shutdown function with output disable
Output swings to 150mV of rails with IO=2A
1.3µV/°C Typical offset drift
80dB Typical CMRR
Green product and no Sb/Br

Show

OPA567AIRHGT Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	12 Pin
Case/Package	VQFN-12
Supply Current	9 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	12 Position
Common Mode Rejection Ratio	80 dB
Input Offset Drift	1.30 µV/K
Bandwidth	1.2 MHz
Slew Rate	1.20 V/μs
Gain Bandwidth Product	1.2 MHz
Input Offset Voltage	500 µV
Input Bias Current	1 pA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	1.2 MHz
Minimum CMRR Range	80 dB
Supply Voltage	2.7V ~ 5.5V
Supply Voltage (Max)	5.5 V
	Show
Size-Length	5 mm
Size-Width	5 mm
Size-Height	0.9 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
