Image is for your reference only,please check specifications for details

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The OPF482 is a low noise Silicon PIN Photodiode. The fibre optic detector offers fast response at moderate bias and is compatible with LED and laser diode sources in the 800 to 1000nm wavelength region. Low capacitance improves signal to noise performance in typical short haul LAN applications. It is designed to be compatible with multimode optical fibres from 50/125 to 200/300 microns.
High speed, low capacitance
Popular ST® style receptacle
Pre-tested with fibre to assure performance
Component pre-mounted and ready to use
100MHz Operation minimum

Show

OPF482 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	ST-Tall
Supply Voltage (DC)	5.00 V
Supply Current	5 nA
Number of Positions	3 Position
Wavelength	860 nm
Peak Wavelength	905 nm
Power Dissipation	200 mW
Rise Time	1 ns
Reverse Breakdown Voltage	100 V
Fall Time	1 ns
Fall Time (Max)	2 ns
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	200 mW
	Show
Size-Length	10.41 mm
Size-Width	10.41 mm
Size-Height	20.57 mm
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
