Description

The PD84001 is a N-channel RF Power Transistor designed for high gain, broad band applications. It operates at 7V in common source mode at frequencies of up to 1GHz. The superior gain and efficiency makes it an ideal solution for portable radio and UHF RFID reader.
Excellent thermal stability
Common source configuration
Enhancement-mode lateral field-effect transistor
Plastic package

Show

PD84001 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-89
Frequency	870 MHz
Current Rating	1.5 A
Number of Positions	3 Position
Power Dissipation	6 W
Drain to Source Voltage (Vds)	18 V
Output Power	30 dBm
Gain	15 dB
Test Current	50 mA
Input Capacitance (Ciss)	14.7pF @7V(Vds)
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-65 ℃
Power Dissipation (Max)	6000 mW
Voltage Rating	18 V
	Show
Size-Length	4.6 mm
Size-Width	2.6 mm
Size-Height	1.6 mm
Operating Temperature	-65℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
HK STC License	NLR
