Description

This polymer PGB1010402KR ESD protection device from Littelfuse protects against electrostatic discharge. This device"s maximum clamping voltage is 250(Typ) V. This ESD diode has a maximum ESD protection device voltage of 15@Air Gap/8@Contact Disc kV. This ESD diode has an operating temperature range of -65 °C to 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its capacitance value is 0.04(Typ) pF. It is made in a single configuration.

Show

PGB1010402KR Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package (SI)	1005
Case/Package	0402
Voltage Rating (DC)	12.0 V
Operating Voltage	12 V
Capacitance	0.04 pF
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	2 Position
Clamping Voltage	250 V
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-65 ℃
Voltage Rating (Max)	12 VDC
	Show
Size-Length	0.99 mm
Size-Width	0.5 mm
Size-Height	0.31 mm
Operating Temperature	-65℃ ~ 125℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2014/12/17
ECCN Code	EAR99
