Description
- Dump the microprocessor and build your circuit using fundamental logical operations using Texas Instruments" SN74AUC1G08DBVR logic gates. This gate has a minimum operating temperature of -40 °C and a maximum of 85 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This device has a typical operating supply voltage of 1.8|2.5 V. Its minimum operating supply voltage of 0.8 V, while its maximum is 2.7 V.
SN74AUC1G08DBVR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 5 Pin |
| Case/Package | SOT-23-5 |
| Supply Voltage (DC) | 800mV ~ 2.70V |
| Number of Outputs | 1 Output |
| Output Current | 9 mA |
| Number of Circuits | 1 Circuit |
| Number of Positions | 5 Position |
| Number of Bits | 1 Bit |
| Propagation Delay Max (tpd) | 2.00 ns |
| Voltage Nodes | 800 mV, 1.20 V, 1.50 V, 1.80 V, 2.50 V |
| Number of Gates | 1 Gate |
| Output Current Drive | -1.00 mA |
| Number of Inputs | 2 Input |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 0.8V ~ 2.7V |
| Supply Voltage (Max) | 2.7 V |
| Supply Voltage (Min) | 0.8 V |
| Show | |
| Size-Length | 3.05 mm |
| Size-Width | 1.75 mm |
| Size-Height | 1.3 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Cut Tape (CT) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
| ECCN Code | EAR99 |
