Image is for your reference only,please check specifications for details
Updated at 14/10/2026 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Описание/информация о заказе
- Эти устройства содержат четыре независимых NAND- gates с 2 входами. Устройства выполняют логическую функцию:
- Y = A • B или Y = A + B в положительной логике.
- Варианты упаковки включают пластиковые малогабаритные корпуса (D, NS, PS), уменьшенные малогабаритные корпуса (DB) и керамические плоские корпуса (W), керамические чип-носители (FK), а также стандартные пластиковые (N) и керамические (J) DIP-корпуса.
- Также доступен в виде двойного двухвходового положительного NAND- gate в малогабаритном корпусе (PS).
SNJ5400W Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 14 Pin |
| Case/Package | CFP-14 |
| Supply Voltage (DC) | 4.50V ~ 5.50V |
| Number of Bits | 4 Bit |
| Propagation Delay Max (tpd) | 22.0 ns |
| Voltage Nodes | 5.00 V |
| Number of Gates | 4 Gate |
| Output Current Drive | -25.0 µA |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Show | |
| Size-Length | 9.21 mm |
| Size-Width | 6.29 mm |
| Size-Height | 1.59 mm |
| Operating Temperature | -55℃ ~ 125℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
Order guide
-
TT in advance (bank transfer), Western Union, Credit card,
PayPal. Customer is responsible for shipping fee, bank
charges, duties and taxes.
-
- You can choose whether shipping charges will be charged through your shipping account or by us.
- Please confirm with the logistics company in advance for remote areas.
(Additional charges ($35-$50) may apply for delivery in these areas)
- Delivery date: usually 2 to 7 working days.
- A tracking number will be sent after your order ships.
- - Carefully inspected and packed by ManyChip warehouse - Vacuum packaging - Anti-static packaging - Shockproof foam
- The terms here are for reference only, the actual terms are subject to the sales quotation. - Please confirm product specifications when ordering. - MOQ refers to the minimum order quantity required to purchase each part. - If you have special ordering instructions, please indicate them on the ordering page. - Inspection (PSI) will be performed prior to shipment.
- - Income Quality Control (IQC), 1000+ qualified dealers. - Chips are tested by authoritative organizations to ensure the quality, authenticity and safety of your device. - Decapsulation control - X-ray control - XRF inspection - Electrical testing - Surface testing -Digital components warehouse, covering an area of 800 square meters, with constant temperature and humidity
