Image is for your reference only,please check specifications for details

STPS2L60 - ST Microelectronics
Manufacturer:
ST Microelectronics
ManyChip's Part#:
MC8283126
Category:
Schottky Diode
Package:
DO-41
Datasheet:
Datasheet 3D Model
Description:
Schottky Rectifier, 60V, 2A, Single, DO-41 (DO-204AL), 2Pins, 600mV
Stock Locations:
Availability:
290 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.13

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The STPS2L60 is a power Schottky Rectifier features negligible switching losses, low forward voltage drop and surface mount miniature package. This device is especially intended for use in low voltage, high frequency inverters and small battery chargers.
1600W Repetitive peak avalanche power (tp=1µs, Tj=25°C)
30°C/W Junction-to-lead thermal resistances
Avalanche capability specified

Show

STPS2L60 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	DO-41
Voltage Rating (DC)	60.0 V
Current Rating	2.00 A
Output Current	≤2.00 A
Number of Positions	2 Position
Forward Voltage	600mV @2A
Polarity	Standard
Thermal Resistance	30℃/W (RθJL)
Forward Current	2 A
Max Forward Surge Current (Ifsm)	75 A
Maximum Forward Voltage (Max)	600 mV
Forward Current (Max)	2 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature	150℃ (Max)
Junction Temperature (Max)	150 ℃
	Show
Size-Length	5.2 mm
Size-Width	2.71 mm
Size-Height	2.71 mm
Operating Temperature	-65℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
