TC7660SEOA - Microchip
Manufacturer:
Microchip
ManyChip's Part#:
MC14894057
Category:
DC to DC Converter
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
MICROCHIP TC7660SEOA DC-DC Adjustable Charge Pump Voltage Converter, 1.5V to 12V in, -12V to -1.5V/20mA out, SOIC-8
Stock Locations:
Availability:
4 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.95

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TC7660SEOA is a super charge pump DC-to-DC Voltage Converter for RS-232 negative power supply. The TC7660S device is a pin-compatible replacement for the industry standard 7660 charge pump voltage converter. It converts a +1.5 to +12V input to a corresponding -1.5 to -12V output using only two low-cost capacitors, eliminating inductors and their associated cost, size and electromagnetic interference (EMI). Added features include an extended supply range to 12V and a frequency boost pin for higher operating frequency, allowing the use of smaller external capacitors. The on-board oscillator operates at a nominal frequency of 10kHz. Frequency is increased to 45kHz when pin 1 is connected to V+. Operation below 10kHz (for lower supply current applications) is possible by connecting an external capacitor from OSC to ground (with pin 1 open).
Oscillator boost from 10 to 45kHz
Converts +5V logic supply to ±5V system
Efficient voltage conversion of 99.9%
Excellent power efficiency of 98%
Low power supply of 80µA at 5VIN
Improved ESD protection-up to 10kV
No external diode required for high voltage operation
ESD sensitive device, take proper precaution while handling the device.

Show

TC7660SEOA Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Frequency	45 kHz
Number of Outputs	1 Output
Input Voltage (DC)	1.50V (min)
Output Voltage	-12.0 V
Output Current	20 mA
Supply Current	0.16 mA
Number of Positions	8 Position
Power Dissipation	0.47 W
Output Power	470 mW
Switching Frequency	10kHz ~ 45kHz
Input Voltage (Max)	12 V
Input Voltage (Min)	1.5 V
Output Current (Max)	20 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	470 mW
Input Voltage	1.5V ~ 12V
	Show
Size-Length	5 mm
Size-Width	3.99 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
HK STC License	NLR
