TPD1E10B09QDPYRQ1 - TI
Manufacturer:
TI
ManyChip's Part#:
MC88372985
Category:
Diode
Package:
X1SON-2
Datasheet:
Datasheet 3D Model
Description:
ESD Suppressors / TVS Diodes TPD1E10B09-Q1 Automotive 1CH ESD in 0402 Pkg w/ 10pF Capacitance and 9V Breakdown Evaluation Module
Stock Locations:
Availability:
201 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.59

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TPD1E10B09-Q1 device is a bidirectional electrostatic discharge (ESD) transient voltage suppression (TVS) diode in a small 0402 industry standard package. This TVS protection diode is convenient for component placement in space-saving applications and features low RDYN and high IEC rating. The TPD1E10B09-Q1 is rated to dissipate ESD strikes above the maximum level specified in the IEC 61000-4-2 international standard (Level 4) offering ±20-kV contact discharge and ±20-kV IEC air-gap protection. ESD voltages can easily reach 5-kV and during extreme conditions these voltages can be significantly higher, causing damages to many integrated circuits. For example, in a low humidity environment voltages can exceed 20-kV.
The low dynamic resistance (0.5 Ω) and low clamping voltage (13 V at 1-A IPP) ensures system level protection against transient events, providing robust protection on designs that are exposed to ESD events. This device also features a 10-pF IO capacitance making it ideal for audio lines, push buttons, memory interfaces, or GPIOs.
This device is also available without automotive qualification: TPD1E10B09.
