Image is for your reference only,please check specifications for details
- TPS7A4001MDGNREP - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC94513106
-
Category:Voltage Regulator
-
Package:PowerPad-MSOP-8
-
Datasheet:Datasheet 3D Model
-
Description:Standard Regulator Pos 1.161V to 90V 50A Automotive Medical 8Pin HVSSOP EP T/R
-
Stock Locations:
-
Availability:224 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 13.46
Updated at 02/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The TPS7A4001-EP device is a very high voltage-tolerant linear regulator that offers the benefits of a thermally-enhanced package (HVSSOP) and is able to withstand continuous DC or transient input voltages of up to 100 V.
- The TPS7A4001-EP device is stable with any output capacitance greater than 4.7 µF and any input capacitance greater than 1 µF (over temperature and tolerance). Therefore, implementations of this device require minimal board space because of its miniaturized packaging (HVSSOP) and a potentially small output capacitor. In addition, the TPS7A4001-EP device offers an enable pin (EN) compatible with standard CMOS logic to enable a low-current shutdown mode.
- The TPS7A4001-EP device has an internal thermal shutdown and current limiting to protect the system during fault conditions. The TPS7A4001-EP device has an operating temperature range of TJ = -55°C to 125°C.
- In addition, the TPS7A4001-EP device is ideal for generating a low-voltage supply from intermediate voltage rails in telecom and industrial applications; not only can it supply a well-regulated voltage rail, but it can also withstand and maintain regulation during very high and fast voltage transients. These features translate to simpler and more cost-effective electrical surge-protection circuitry for a wide range of applications, including PoE, bias supply, and LED lighting.
TPS7A4001MDGNREP Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | PowerPad-MSOP-8 |
| Number of Outputs | 1 Output |
| Output Voltage | 1.161V ~ 90V |
| Output Current | 50 mA |
| Supply Current | 65 µA |
| Quiescent Current | 20.0 µA |
| Output Capacitor Type | Ceramic |
| voltage rating | 290 mV |
| Number of Regulated Outputs | 1 Output |
| Input Voltage (Max) | 100 V |
| Input Voltage (Min) | 7 V |
| Output Voltage (Max) | 90 V |
| Output Voltage (Min) | 1.161 V |
| Output Current (Max) | 0.05 A |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | 55 ℃ |
| Accuracy | ±1 % |
| Show | |
| Operating Temperature | -55℃ ~ 125℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
