Description

The USB6B1RL is a data line ESD Protection Device. It protects the two input lines against overvoltage. Besides, this device also keeps the power rails in a safe limit.
Full diode bridge with integrated clamping protection
Very low capacitance
Provides protection for each line and between the supply voltage
Separated inputs and outputs (so-called 4-point structure) to improve ESD susceptibility
6V Minimum Breakdown voltage
10µA Leakage current
ESD sensitive device, take proper precaution while handling the device.

Show

USB6B1RL Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Voltage Rating (DC)	6.00 V
Operating Voltage	5.25 V
Capacitance	25 pF
Power Rating	500 W
Breakdown Voltage	6 V
Number of Circuits	2 Circuit
Number of Positions	8 Position
Power Dissipation	500 W
Test Current	1 mA
Peak Pulse Power	500 W
Min Breakdown Voltage	6 V
Reverse Breakdown Voltage	6 V
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
	Show
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.25 mm
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
