Description

Using the high side VN800PT power switch from STMicroelectronics, you"ll get the fastest on and off response when dealing with high currents and voltages. This charge controller has single output. This device has a maximum power dissipation of 41700 mW. It features 0.135(Max) Ohm switch on resistance. This charge controller has an input voltage of -3 to 41 V. Its maximum power dissipation is 41700 mW. This device has a supply current of 2 mA and a minimum output current of 0.7 A. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This charge controller has a minimum operating temperature of -40 °C and a maximum of 150 °C.

Show

VN800PT Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	5 Pin
Case/Package	TO-252-5
Supply Voltage (DC)	36.0V (max)
Number of Outputs	1 Output
Supply Current	20.0 mA
Number of Channels	1 Channel
Drain to Source Resistance (on) (Rds)	270 mΩ
Power Dissipation	41700 mW
Output Current (Max)	700 mA
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Supply Voltage	5.5V ~ 36V
	Show
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Unknown
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
ECCN Code	EAR99
