Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Case/Package (SI) | 3216 |
Case/Package | 1206 |
Time to Trip | 1 s |
Power Dissipation | 0.4 W |
Resistance | 15 Ω |
Holding Current | 0.1 A |
Trip Current | 250 mA |
Current Rating (Max) | 10 A |
Holding Current (Max) | 100 mA |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -40 ℃ |
Voltage Rating (Max) | 60 VDC |
Voltage Rating | 60 VDC |
Show | |
Size-Length | 3.2 mm |
Size-Width | 1.6 mm |
Size-Height | 0.85 mm |
Operating Temperature | -40℃ ~ 85℃ |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
ECCN Code | EAR99 |
