Description

The 78250C is a 300mA fully encapsulated Converter Isolation Transformer with toroidal construction, matte tin pin finish and surface mount, it is designed for use with Maxim chipsets to provide isolated RS-232 interfaces, carefully controlled turns ratios ensure consistent performance. This transformer features industry-standard pinout and industrial temperature range.
Up to 4kVrms Isolation
300°C Lead temperature 1.5mm from case for 10 seconds
-40 to 85°C Operating free air temperature range

Show

78250C Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	5 Pin
Case/Package	DIP
Current Rating	300 mA
Output Current	300 mA
Inductance	2 mH
DC Resistance (DCR)	1 Ω
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
	Show
Size-Length	9 mm
Size-Width	10.19 mm
Size-Height	6.35 mm
Weight	1.00 g
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
