AD5235BRUZ25 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC296283
Category:
Digital Potentiometer IC
Package:
TSSOP-16
Datasheet:
Datasheet 3D Model
Description:
Digital Potentiometer 25KΩ 1024POS Non-Volatile Linear/Log 16Pin TSSOP Tube
Stock Locations:
Availability:
254 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 17.25

Updated at 24/10/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD5235BRUZ25 is a Dual 1024-position Non-volatile Memory Digital Potentiometer offering guaranteed maximum low resistor tolerance error of ±8%. The device performs the same electronic adjustment function as a mechanical potentiometer with enhanced resolution, solid state reliability and superior low temperature coefficient performance. The versatile programming of the AD5235 via an SPI®-compatible serial interface allows 16 modes of operation and adjustment including scratchpad programming, memory storing and restoring, increment/decrement, ±6dB/step log taper adjustment, wiper setting readback and extra EEMEM for user defined information such as memory data for other components, look-up table or system identification information. In the scratchpad programming mode, a specific setting can be programmed directly to the RDAC2 register, which sets the resistance between Terminal W and Terminal A and Terminal W and Terminal B.
Maximum ±8% nominal resistor tolerance error
Low temperature coefficient
SPI-compatible serial interface
Non-volatile memory stores wiper settings
Power-on refreshed with EEMEM settings
Permanent memory write protection
Resistance tolerance stored in EEMEM
26-byte Extra non-volatile memory for user-defined information
1M Programming cycles
100 years Typical data retention
ESD sensitive device, take proper precaution while handling the device.

Show

AD5235BRUZ25 Specifications
