AD5348BRUZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC583165
Category:
Digital to Analog, DAC IC
Package:
TSSOP-38
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD5348BRUZ Digital to Analog Converter, 12Bit, 125KSPS, Parallel, 2.5V to 5.5V, TSSOP, 38Pins
Stock Locations:
Availability:
229 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 17.77

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD5348BRUZ is an octal 12-bit Digital-to-analog Converter (DAC) operating from a 2.5 to 5.5V supply. This device incorporates an on-chip output buffer that can drive the output to both supply rails. It has a parallel interface. CS selects the device and data is loaded into the input registers on the rising edge of WR. A read-back feature allows the internal DAC registers to be read back through the digital port. An asynchronous CLR input is also provided, which resets the contents of the input register and the DAC register to all zeros. This device also incorporates a power-on reset circuit that ensures that the DAC output powers on to 0V and remains there until valid data is written to the device. It is pin compatible, which allows users to select the amount of resolution appropriate for its application without redesigning its circuit board.
Input data to the DAC is double-buffered
Guaranteed monotonic by design over all codes
Simultaneous update of DAC outputs via LDAC pin
Asynchronous CLR facility

Show

AD5348BRUZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	38 Pin
Case/Package	TSSOP-38
Number of Outputs	8 Output
Supply Current	1.00 mA
Number of Channels	8 Channel
Number of Positions	38 Position
Number of Bits	12 Bit
Power Dissipation	8.3 mW
Sample Rate	125 ksps
Resolution (Bits)	12.0 Bit
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Number of DACs	8 DAC
Supply Voltage	2.5V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.5 V
	Show
Size-Length	9.8 mm
Size-Width	4.5 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
