AD627BRZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC339193
Category:
Instrumentation Amplifier IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
Micropower, Single- and Dual-Supply, Rail-to-Rail Instrumentation Amplifier, Input Offset Voltage:125V, Bandwidth:80kHz, CMRR:96dB, Slew Rate:0.05V/s, Supply Voltage Range: 1.1V to 18V, Supply Current:60A, SOIC-8
Stock Locations:
Availability:
283 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 11.83

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD627BRZ is an Instrumentation Amplifier that delivers rail-to-rail output swing on single and dual (+2.2 to ±18V) supplies. The AD627 provides excellent AC and DC specifications while operating at only 85µA maximum. The AD627 offers superior flexibility by allowing the user to set the gain of the device with a single external resistor while con-forming to the 8-lead industry-standard pinout configuration. With no external resistor, the AD627 is configured for a gain of 5. With an external resistor, it can be set to a gain of up to 1000. The AD627 provides superior performance, uses less circuit board area and costs less than micropower discrete designs.
Higher performance than discrete designs

Show

AD627BRZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	18.0 V
Operating Voltage	3.6V ~ 2.2V
Supply Current	60 µA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Power Dissipation	0.8 W
Common Mode Rejection Ratio	96 dB
Bandwidth	80 kHz
Slew Rate	50.0 mV/μs
Input Offset Voltage	125 µV
Input Bias Current	2 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	80 kHz
Gain Bandwidth	83 dB
Power Dissipation (Max)	800 mW
Minimum CMRR Range	83 dB
Supply Voltage	1.1V ~ 18V
Supply Voltage (Max)	30V ~ 50V
Supply Voltage (Min)	1.1 V
	Show
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
ECCN Code	EAR99
