Description

Analog Devices offers this AD737JRZ RMS to DC converter to analyze AC signals with low-latency and high accuracy. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This RMS to DC converter has a minimum operating temperature of 0 °C and a maximum of 70 °C.

Show

AD737JRZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Current	170 µA
Number of Positions	8 Position
Input Current	0.16 mA
Power Dissipation	200 mW
Bandwidth	170 kHz
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
3dB Bandwidth	190kHz, 460kHz
Power Dissipation (Max)	200 mW
Accuracy	0.3 %
Supply Voltage	2.5.16.5 VDC
	Show
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
