AD8250ARMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC1388473
Category:
Instrumentation Amplifier IC
Package:
MSOP-10
Datasheet:
Datasheet 3D Model
Description:
Instrument Amplifier, 1 Amplifier, 20V/µs, 10MHz, ± 5V to ± 15V, MSOP
Stock Locations:
Availability:
226 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 9.48

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8250ARMZ is an iCMOS Programmable Gain Instrumentation Amplifier with digitally programmable gains that has GR input impedance, low output noise and low distortion making it suitable for interfacing with sensors and driving high sample rate analogue-to-digital converters (ADCs). The combination of precision DC performance coupled with high speed capabilities makes it an excellent candidate for data acquisition. Furthermore, this monolithic solution simplifies design and manufacturing and boosts performance of instrumentation by maintaining a tight match of internal resistors and amplifiers. The user interface consists of a parallel port that allows users to set the gain in one of two ways. A 2-bit word sent via a bus can be latched using the WR input. An alternative is to use the transparent gain mode where the state of the logic levels at the gain port determines the gain.
Digital or pin-programmable gain setting
Excellent DC performance
10ppm/°C Maximum gain drift
1.7µV/°C Maximum offset drift (G = 10)
Excellent AC performance
615ns to 0.001% Maximum fast settling time
Low distortion
18nV/√Hz Noise
Low power
ESD sensitive device, take proper precaution while handling the device.

Show

AD8250ARMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	MSOP-10
Supply Current	4.1 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	10 Position
Common Mode Rejection Ratio	110 dB
Bandwidth	10 MHz
Slew Rate	20.0 V/μs
Gain Bandwidth Product	10 MHz
Input Offset Voltage	270 µV
Input Bias Current	5 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	10 MHz
Minimum CMRR Range	80 dB
Supply Voltage (Max)	30V ~ 50V
	Show
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	PB free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
HK STC License	NLR
