AD826 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC211272707
RoHS:
Lead free / RoHS Compliant
Datasheet:
Datasheet 3D Model
Description:
High Speed, Low Power Dual Operational Amplifier
Stock Locations:
Availability:
323 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Product Details
The AD826 is a dual, high speed voltage feedback op amp. It is ideal for use in applications which require unity gain stability and high output drive capability, such as buffering and cable driving. The 50 MHz bandwidth and 350 V/µs slew rate make the AD826 useful in many high speed applications including: video, CATV, copiers, LCDs, image scanners and fax machines.
The AD826 features high output current drive capability of 50 mA min per amp, and is able to drive unlimited capacitive loads. With a low power supply current of 15 mA max for both amplifiers, the AD826 is a true general purpose operational amplifier.
The AD826 is ideal for power sensitive applications such as video cameras and portable instrumentation. The AD826 can operate from a single +5V supply, while still achieving 25 MHz of bandwidth. Furthermore the AD826 is fully specified from a single +5V to ±15V power supplies.
The AD826 excels as an ADC/DAC buffer or active filter in data acquisition systems and achieves a settling time of 70 ns to 0.01%, with a low input offset voltage of 2mV max. The AD826 is available in small 8-pin plastic mini-DIP and SO packages.
### Features and Benefits
High Speed:
50 MHz Unity Gain Bandwidth
350 V/µs Slew Rate
70 ns Settling Time to 0.01%
Easy to Use:
Drives Unlimited Capacitive Loads
50 mA Min Output Current Per Amplifier
Specified for +5 V, ±5 V and ±15 V Operation
2.0 V p-p Output Swing into a
150 Ω Load (Vs = +5 V)
Low Power:
7.5 mA Max Power Supply
Current Per Amp
Good Video Performance
Differential Gain & Phase
Error of 0.07% & 0.11°
Excellent DC Performance:
2.0 mV Max Input Offset Voltage

Show

AD826 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Case/Package	SOIC
	Show
Product Lifecycle Status	Unknown
RoHS	RoHS Compliant
